Silicone meter hose
Silicone meter hose is made of high-quality silicone material with excellent performance and reliable quality. We can produce silicone instrument hose according to your drawing.
Product Introduction
- Inner: 100% High quality silicone
- Cover: Silicone
- Reinforcement: 4 ply of polyester/aramid/glass fiber
- Temperature: -40℃（-40 ℉ ）to +220℃ (+428 ℉ )
- Color: Blue/Black/Red/Green/Yellow/Pink/Orange, etc (Customizable color)
Detailed Specs
| INCH SIZE | ID | LAYER | THICKNESS | LENGTH | INCH SIZE | ID | LAYER | THICKNESS | LENGTH |
|---|---|---|---|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | mm | ||||
| 1/4″ | 6 | 3-4 | 4-4.5 | 1000 | 1-1/2″ | 38 | 4 | 4.5-5 | 1000 |
| 5/16″ | 8 | 3-4 | 4-4.5 | 1000 | 1-3/4″ | 45 | 4 | 4.5-5 | 1000 |
| 3/8″ | 10 | 3-4 | 4-4.5 | 1000 | 2″ | 51 | 4 | 4.5-5 | 1000 |
| 1/2″ | 12 | 3-4 | 4-4.5 | 1000 | 2-1/4″ | 57 | 4 | 4.5-5 | 1000 |
| 5/8″ | 16 | 3-4 | 4-4.5 | 1000 | 2-1/2″ | 63 | 4 | 4.5-5 | 1000 |
| 3/4″ | 19 | 3-4 | 4-4.5 | 1000 | 2-3/4″ | 70 | 4 | 4.5-5 | 1000 |
| 1″ | 25 | 4 | 4.5-5 | 1000 | 3″ | 76 | 4 | 4.5-5 | 1000 |
Silicone Meter Hose Features
●Corrosion resistance: Our silicone metering hoses can withstand various chemicals and acid and alkali environments, and are not easily corroded and oxidized.
●High temperature resistance: Our silicone metering hose can withstand high temperature environment and can maintain its elasticity and stability in the temperature range.
●High Elasticity: Our silicone metering hose has excellent elasticity and can maintain its original shape and performance during use.
●Safe and reliable: Our silicone metering hoses have been tested and inspected many times to ensure that they meet various international standards and safety requirements.(Such as FDA certification, ROHS certification, REACH certification, etc.)
●We offer OEM/ODM, We can 3D design, produce according to your drawings
silicone Meter Hose Production & Packing
Silicone Meter Hose Application
Heating and cooling systems; charge-air-cooler (hot & cold side); Turbo charger systems & custom compressor,intercooler or intake & inlet piping for turbo/Superchargers, etc.
After-sales service
In addition to high-quality products, we also provide professional technical support and consulting services. Our professional team can provide customers with personalized solutions to meet customer-specific needs. Our customer service team is always ready to support customers, whether it is about product selection, order tracking or after-sales service, we will do our best to solve problems for customers.
